The white paper, HSPA to LTE-Advanced: 3GPP Broadband Evolution to IMT-Advanced (4G), discusses the 3GPP evolution of EDGE, HSPA and LTE, their capabilities and their positions relative to other primary competing technologies and how these technologies fit into the ITU roadmap that leads to IMT-Advanced.
The following are some of the important observations and conclusions of the report:
- HSPA Evolution (HSPA+) provides a strategic performance roadmap advantage for GSM-HSPA operators. Features such as dual-carrier operation, MIMO and higher-order modulation offer operators multiple options for improving their networks, and some of these features are simply network software upgrades.
- Persistent innovation in developing HSPA and HSPA+ is bringing UMTS to its full potential providing mobile broadband to the mass market; in current deployments, HSPA users regularly experience throughput rates well in excess of 1 Mbps under favorable conditions, on both downlinks and uplinks, with 4 Mbps downlink speed commonly being measured. Planned enhancements such as dual-carrier operation will double peak user-achievable throughput rates.
- LTE has become the next-generation platform of choice for GSM-HSPA and CDMA/EV-DO operators.
- The 3GPP OFDMA approach used in LTE matches or exceeds the capabilities of any other OFDMA system providing the most powerful wide area wireless technology ever developed. Peak theoretical downlink rates are 326 Mbps in a 20 MHz channel bandwidth.
- 3GPP has made significant progress investigating how to enhance LTE to meet the requirements of IMT-Advanced in a project called LTE-Advanced.
With a customer base of 4 billion connections today, the GSM family of technologies is available on nearly 800 networks in 219 countries worldwide. Building on this base, UMTS-HSPA – the world’s dominant mobile broadband technology today – has proven to be the most widely deployed and adopted 3G technology of all time, with more than 352 operators in various stages of deployment, including 277 commercial HSPA networks in 116 countries.
The white paper explains the tremendous opportunity afforded to GSM-HSPA operators via the 3GPP roadmap to HSPA+. While OFDMA systems such as LTE and WiMAX have attracted a great amount of attention, evolving HSPA to exploit available radio technologies can significantly enhance its performance capabilities and extend the life of sizable operator HSPA infrastructure investments. Techniques include advanced receivers, MIMO, Continuous Packet Connectivity, Higher-Order Modulation and One Tunnel Architecture, many of which are included in the standardization of 3GPP Release 7 and Release 8.Depending on the features implemented, HSPA+ can exceed the capabilities of IEEE 802.16e-2005 (Mobile WiMAX Release-1) in the same amount of spectrum. Beyond the peak data rate of 42 Mbps for HSPA+ in Release 8 (with 2X2 MIMO, DL 64 QAM and UL 16 QAM), Release 9 may specify 2X2 MIMO in combination with dual-carrier operation, which would further boost peak theoretical downlink network rates to 84 Mbps. In addition to the increased speeds, HSPA+ also will more than double HSPA capacity and has the potential of reducing latency to below 25 milliseconds.
HSPA and HSPA+ will continue to dominate mobile broadband subscriptions worldwide for the remainder of this decade and well into the next. However, announcements have already begun in support of the next 3GPP evolutionary step, LTE. Trials and deployments of LTE will begin in 2010 by leading operators including AT&T, China Mobile, China Telecom, NTT DoCoMo, Verizon and Vodafone. In fact, today there are more than 2 billion subscriptions represented by combining the total existing customer bases of the more than 100 operators, both GSM and CDMA operators, who have announced indications of their intention to deploy LTE networks.
The deployment of LTE and its coexistence with UMTS-HSPA will be analogous to the deployment of UMTS-HSPA and its coexistence with GSM-EDGE.
Whitepaper available to download here.
Accompanying slide presentation available here.
2 comments:
Hello, I was a delegate at the LTE World Conference in Berlin. :) I follow this blog very closely and I think you proide some great insight. I was wondering if you knew a good reference that illustrated a data call over an LTE network from end-to-end? If not, that might be a good thing to post about. Thank you!
Havent come across anything but will surely create an MSC. I did basic UE Registration here but will add one for data call as well.
